产品详情
主要特点
▲整机由PLC，简便直观。
▲制袋、计量、充填、封合、切断、计数全自动完成。
▲伺服控制皮带拉袋动作。
▲智能温控系统，封合平整美观。
▲电眼追踪色点，准确切断。
MAIN FEATURE
▲The whole machine is PLC, which is simple and intuitive.
▲Bag making, metering, flling, sealing, cutting and counting are fully automatic.
▲Servo control belt pull bag action.
▲Intelligent temperature control system, the seal is flat and beautiful.
▲The electric eye tracks the color point and cuts it off accurately.
技术参数TECHNICAL PARAMETERS | |
型号Model | TJF-200 |
最大膜宽Maximum film width(mm) | 200 |
袋宽范围Bag width range(mm) | 30-60 |
袋长范围Bag length range(mm) | 50-200 |
包装速度Packing speed(bag/min) | 15-50 |
压缩空气用量Compressed air usage | 6kg/m² 0.3m³/min |
机器尺寸Machine size(mm) | 1018x1400x1710 |
整机重量Machine weight(kg) | 350 |
