主要特点
▲整机由PLC或单片机控制，简便直观。
▲制袋、计量、充填、封合、切断、计数全自动完成。
▲纯机械动作，工作更可靠，维护保养更方便。
▲智能温控系统，封合平整美观。
▲电眼追踪色点，准确切断。
MAIN FEATURE
▲The whole machine is controlled by PLC or single chip microcomputer, which is simple and intuitive.
▲Bag making, metering, flling, sealing, cutting and counting are fully automatic.
▲Pure mechanical action, more reliable work, more convenient maintenance.
▲Intelligent temperature control system, the seal is flat and beautiful.
▲The electric eye tracks the color point and cuts it off accurately.
技术参数TECHNICAL PARAMETERS | |
型号Model | TJJ-300 |
最大膜宽Maximum film width(mm) | 300 |
计量范围Measuring range(ml) | 1-150(更换活塞泵Replace the piston pump) |
袋宽范围Bag width range(mm) | 30-140 |
袋长范围Bag length range(mm) | 30-170 |
包装速度Packing speed(bag/min) | 30-60 |
机器尺寸Machine size(mm) | 750x1000x1750 |
整机重量Machine weight(kg) | 250 |
