主要特点
▲本设备的整个传动简单，并装有无瓶停机、有瓶开机的装置，和无干燥剂、干燥剂堵塞报警等安全保护装置。
▲本设备是机电一体化的设备，操作方便、维修简单、运行可靠。采用全中文界面触摸屏，PLC微机控制系统，有记数、工作参数设定、显示等功能，在参数范围内可任意调整。
▲采用气动拦夹瓶机构，使机器工作时既平稳又可靠。
▲主要采用变频调速自动控制技术，主机速度可自行调节，避免了国内同类机生产速度、调整方式不灵活的弊病。
▲机内装有自动安全保护装置，在瓶子未到达生产工位时，主机不工作，确保生产过程中塞干燥剂动作准确性。
MAIN FEATURE
▲The whole transmission of the equipment is simple, and it is equipped with a device without bottle stop, a bottle starter, and a safety protection device such as no desiccant and desiccant block alarm.
▲This equipment is a mechatronics equipment with convenient operation, simple maintenance and reliable operation. It adopts full Chinese interface touch screen, PLC microcomputer control
system, with counting, working parameter setting, display and other functions, which can be adjusted freely within the parameter range.
▲The pneumatic bottle clamping mechanism is adopted to make the machine work smoothly and reliably.
▲Mainly adopts the frequency conversion speed control automatic control technology, the host speed can be adjusted by itself, avoiding the disadvantages of the domestic similar machine production speed and adjustment method is not flexible.
▲The machine is equipped with automatic safety protection device. When the bottle does not reach the production station, the main machine does not work, ensuring the accuracy of the desiccant action during the production process.
技术参数TECHNICAL PARAMETERS | |
型号Model | BPG-200 |
生产能力Production capacity | (视包装物)130瓶/分钟以下，且速度可调(depending on the package) 130 bottles / min or less, and adjustable speed |
瓶子适应规格(ml) | 350ml |
电压/频率Voltage/frequency(V/Hz) | 220/50 |
总功率Power(kw) | 0.5 |
用气量Gas consumption(m³/h) | 0.1 |
外形尺寸Dimension(L x W x H)(mm) | 1600x 750x 2000 |
重量Weight(kg) | 280 |
