主要特点
▲采用通道振动均匀下料，运行可靠平稳，噪音低。
▲采用独特的抗高粉尘光电传感器。
▲光电传感器自动计数，计数准确，装瓶误差小于国家标准。
▲采用智能化设计，人机对话，中文菜单，各种运行参数根据需要进行设置，可存储几十组设置参数，以便调用;可外接存储设备，增大存储量。
▲操作简单、拆卸、清洗，更换部件简单方便。
▲配置除尘盒，减少粉尘污染。
MAIN FEATURE
▲The channel vibration is evenly cut, the operation is reliable and stable, and the noise is low.
▲Using a unique anti-high dust photoelectric sensor.
▲Photoelectric sensors are automatically counted, the counting is accurate, and the bottling error is less than the national standard.
▲Intelligent design, man-machine dialogue, Chinese menu, various operating parameters are set as needed, and dozens of setting parameters can be stored for calling; external storage devices can be connected to increase storage capacity.
▲Simple operation, disassembly, cleaning, and easy replacement of parts.
▲Configure the dust box to reduce dust pollution.
技术参数TECHNICAL PARAMETERS | |
型号Model | BPS-D8 |
生产能力Production capacity | 最大生产速度3500-4500粒/分(视药物而定)The maximum production speed is 3500-4500 capsules/min (depending on the drug) |
每瓶可装数量The number of bottles per bottle | 2-9999任意设定Arbitrarily set |
瓶口直径Bottle diameter(mm) | 20~100 |
电压/频率Voltage/frequency(V/Hz) | 单相AC 220V, 50/60Hz |
气压源Air pressure source(Mpa) | 0.6 |
功率Power(kw) | 1000 |
用气量Gas consumption(m³/h) | 0.1 |
外形尺寸Dimension(L x W x H)(mm) | 1600 x 1600 x 1700(高度可调Height adjustable) |
重量Weight(kg) | 280 |
