主要用途
本机是在吸收消化进口设备的基础上,精心设计完成;采用进口电器元件,PLC控制系统;是一种高档次、高节能、高节材新型捆包机械设备,具有运行稳定、操作简单等特点。本机的优点是由带状薄膜对纸盒或有规则形状的物体进行局部捆扎包装替代中盒包装,相对于其他全封闭的薄膜包装大大降低成本;其最大亮点是整机速度可达到30包/分钟,变化包装规格时无须更换零件,最大程度上提高生产效率。是目前包装机械行业中替代中盒进行集合包装最理想的包装设备。该系列机广泛适用于药品、食品、化妆品、保健用品、文化用品等各种尺寸的盒装物品的组合包装,如盒装药品、食品、口香糖、茶叶、香水、扑克牌、磁带、VCD/DVD等。
MAIN PURPOSE
This machine is carefully designed and finished on the basis of absorbing and digesting imported equipment; it adopts imported electrical components and PLC control system; it is a new type of high-grade, high energy-saving and high-materials strapping machinery and equipment, with stable operation and simple operation. The advantage of this machine is that the strip film or the regular shape of the object is partially bundled to replace the middle box package, which greatly reduces the cost compared with other fully enclosed film packages; the biggest highlight is that the whole machine speed can reach 30 bags. / min, no need to replace parts when changing the packaging specifications, to maximize production efficiency. It is the most ideal packaging equipment for the assembly of the middle box in the packaging machinery industry.This series of machines is widely used in combination packaging of various sizes of medicines, foods, cosmetics, health products, stationery, etc., such as boxed medicines, food, chewing gum, tea, perfume, playing cards, tapes, VCD/DVD. Wait.
技术参数TECHNICAL PARAMETERS | |
型号Model | KB-400 |
最大包装尺寸Max packing size(mm) | 380x200x120 |
最小包装尺寸Min packing size(mm) | 80x50x30 |
工作速度Packing speed(bag/min) | 15-35 |
工作电源Power source | 220V/50Hz |
工作功率Machine power(kw) | 600 |
工作气压Compressed air(mpa) | 0.5-0.6 |
用气流量Air flow(m³/minute) | 0.2 |
外形尺寸Overall size(mm) | 主机Main machine 1150 x 600x 1500 |
输送Conveyer part 1200 x 220 x 800 | |
设备重量Weight(kg) | 600 |
