主要特点
▲该机采用PLC和触摸 屏控制，变频调速，自动化程度高，操作方便。
▲配置感应自检机构,能自动剔除缺粒废板。
▲主传动部分采用进口齿轮减速机，性能好寿命长，噪音低，运转平稳。
▲光标跟踪对版，封合整齐美观。
▲可选配光纤或摄像检测。
MAIN FEATURE
▲The machine adopts PLC and touch screen control, frequency conversion speed regulation, high degree of automation and convenient operation.
▲Configure the self-testing mechanism to automatically remove the missing waste board.
▲The main transmission part adopts imported gear reducer, which has good performance, long service life, low noise and stable operation.
▲The cursor tracks the version, and the seal is neat and beautiful.
▲Optional fiber or camera detection.
主要用途
本机是我公司创新设计的药物包装机械,其功能达到国内先进水平。本机适用于制
药、食品、电子、医疗器械等行业的胶囊、片剂、针剂、蜜丸、糖果、一次性注
射器等物品的铝塑、纸塑和铝铝复合密封包装。
MAIN PURPOSE
This machine is an innovative packaging drug packaging machine of our company, and its function has reached the domestic advanced level. This machine is suitable for aluminum, plastic, paper- plastic and aluminum-aluminum composite sealing. packages of capsules, tablets, injections, honey pills, candy, disposable syringes, etc. in the pharmaceutical, food, electronics, medical equipment and other industries.
技术参数TECHNICAL PARAMETERS | ||||
型号Model | DPP-80 | DPP-140 | DPP-250 | |
冲裁频率Packing speed(times/min) | 20- 40 | 20-40 | 20-45 | |
行程可调范围Range of stroke(mm) | 20- 100 | 40-120 | 40-120 | |
包材规格Packing material | 药用PVC Pharmacy PVC | (0.2-0.4)x 80 | (0.2-0.4)x 140 | (0.2-0.4)x 250 |
铝箔PTP Alu foil (mm) | (0.02-0.05)x 80 | (0.02-0.05)x 140 | (0.02- -0.05)x250 | |
压缩空气Compressed air(pressure) | 0.6-0.8MPa | 0.6-0.8MPa | 0.6-0.8MPa | |
耗气量Air consumption(m/min) | ≥0.2 | ≥0.2 | ≥0.3 | |
功率Power supply | AC380V 50HZ 1.8KW | AC380V 50HZ 5KW | AC380V 50HZ 6.5KW | |
模具冷却水Water chiller for moulds | 自来水或循环水(约60升/小时) Tap water or recycle water with 60L /h consumption | |||
外形尺寸Overall dimension(L xWx H) | 900x460x890 | 3200x 650x 1700 | 3200x 750x 1700 | |
净重Net weight (kg) | 350 | 1200 | 1700 | |
