主要用途.
本产品适用于药板，软管，安品瓿瓶以及相类似物品的间竭装盒，最高速度可达100盒/分包装效率高，品质优。可自动完成说明书的折叠、纸盒打开、板块装盒、打印批号、封口等工作。采用变频调速，人机界面PLC控制。光电监控各部位动作，运行中出现异常，能自动停机显示原因，以便及时排除故障,该机可以单独使用，亦可与泡罩包装机及其它设备连动使用，形成成套流水线。
MAIN PURPOSE
This product is suitable for the exhausting box of medicine board, hose, ampoule and similar items. The maximum speed is up to 100 boxes/min, and the packaging efficiency is high and the quality is excellent. The folding of the manual, the opening of the paper tray, the loading of the plate, the printing of the batch number, the sealing, etc. can be completed automatically. Adopt frequency control, man-machine interface PLC control. Photoelectric monitoring of various parts of the action, abnormal operation during operation, can automatically stop the display of reasons, in order to eliminate the problem in time, the machine can be used alone, can also be used in . conjunction with the blister packaging machine and other equipment to form a complete assembly line.
技术参数TECHNICAL PARAMETERS | |
型号Model | ZH-120B |
生产能力Packing speed(cartons/min) | 60-100 |
纸盒尺寸范围Size of carton box (L x W x H)(mm) | (65~200) x (20~95)x (10~56) |
压缩空气工作压力Pressure of compressed Air(Mpa) | 0.5~0.7 |
耗气量Air consumption(L/min) | 200~300 |
工作噪音Working noise(dB) | ≤80 |
主电机功率Machine power(KW) | 1.2 |
电源Power supply | 380V 50Hz 3Ph |
