主要特点
▲不锈钢结构，有良好的抗腐蚀能力。
▲排风量大，真空吸力强。
▲操作简单，维护方便。
▲粉尘物料可回收，符合GMP要求。
▲采用消音装置，噪音低，运行平稳。
MAIN FEATURE
▲Stainless steel structure, good corrosion resistance.
▲Large air flow, high vacuum suction.
▲Simple operation, convenient maintenance.
▲Dust material can be recycled, comply with GMP requirements.
▲Adopt the silencing technology, low noise, stable running.
主要用途
本机广泛应用于工业生产中容易产生粉尘的设备与环境的吸尘，如制药、食品、化工等行业。本机主材料采用不锈钢，特别适用于有腐蚀性粉尘的场合，是制药行业的压片机、粉碎机、胶囊充填机、数片机等理想的配套设备。
MAIN PUR POSE
This machine is widely used in the industrial production, such as pharmaceutical, food, chemical industries etc. It is an ideal auxiliary equipment for tablet press machine, pulverizer, capsule filling machine and counting machine in the pharmaceutical industry.
技术参数TECHNICAL PARAMETERS | ||||
型号Model | YCD-110 | YCD-150 | YCD-220 | YCD-300 |
功率Power(kw) | 1.1 | 1.5 | 2.2 | 3.0 |
最大流量Max. flow(m³/h) | 140 | 180 | 215 | 305 |
最大压力Max. Pressure(kpa) | <12 | < 13 | <18 | <20 |
真空度Vacuum degree(kpa) | 16.5 | 18.5 | 20.5 | 21.5 |
风量Air flow(I/min) | 2400 | 3600 | 5100 | 6400 |
噪音Noise(db) | <63 | <70 | <72 | < 75 |
机器重量Machine weight(kg) | 95 | 110 | 140 | 180 |
